One Station, Cast Solid Surface Kurve® Wash Basin
Constructed with long-lasting, impact and stain-resistant Corterra® solid surface material, Meridian® Kurve® washbasins are ideal for institutional and public installations. This one-station wash basin features a wall mount, off-floor with wall waste outlet configuration, a curve front design, and is ADA compliant when installed properly. Left and Right Orientations are available to meet design needs.
T/P Mixing Valve is ASSE 1070 compliant and delivers constant water flow by compensating for temperature and pressure fluctuations. Valve is to be field set to 105° Fahrenheit and includes Integral Checks and Screens to prevent cross-flow and contamination. Operating range is 30 PSI - 100 PSI.
Downloads
Resource Type | Title | Description | Answers | File Size | Action | |
|---|---|---|---|---|---|---|
 | | One Station Cast Solid Surface (Corterra®) Kurve® Wash Basin [Model 3791-LO left orientation] ; includes parts drawings | 0 | 2 MB | ||
| | One Station Cast Solid Surface (Corterra®) Kurve® Wash Basin | 0 | 185 KB | ||
 | | One Station, Cast Solid Surface Kurve® Wash Basin [3791-LO | Left Orientation; 3791-RO | Right Orientation] | 0 | 1 MB | ||
| | One Station, Cast Solid Surface Kurve® Wash Basin [3791-LO | Left Orientation; 3791-RO | Right Orientation] | 0 | 414 KB | ||
| | One Station Cast Solid Surface (Corterra®) Kurve® Wash Basin [Model 3791-RO right orientation]; includes parts drawings | 0 | 2 MB | ||
| | Enviro-Glaze Powdercoating Color Chart | 0 | 2 MB | ||
| | Who we are, Our History, Morris Group International Today | 0 | 7 MB | ||
| | Overview of MGI Divisions | 0 | 718 KB | ||
| | The best ways to stay healthy are also the simplest: hand washing with soap and water and staying hydrated. | 0 | 3 MB | ||
| | Cleaning and Care Guide for Stainless Steel, Enviro-Glaze® Powdercoating , Corterra® Solid Surface , & Terrazzo | 0 | 1 MB |
Specifications
| Product Type | Wash Basin |
| Configurations Available | Off-Floor with Wall Waste Outlet (-1) |
| Brand | Meridian, Kurve®, Acorn ConTrols® Inside |
| Material | Corterra® Solid Surface |
| Mounting | Wall Mounted |
| Institutional Applications | Hospital & Treatment Centers, Educational Building, Train Station & Airports, Other Institutional Buildings |
| Commercial Applications | Stores & Shopping Centers, Warehouse, Office Building, Restaurant & Hospitality, Stadium & Arena |
| Bowl Shape | Curve |
| Compliance | UL Greenguard, ADA Compliant, Federal Public Law 111-380, CBC (Calif. Title 24) |
| Overall Dimensions | 24" (Side-to-Side) x 21" (Front-to-Back) |
| Stations-Users | 1 |
Options
Miscellaneous
Image | Model | Description | Downloads | |
|---|---|---|---|---|
 | DV | Option: Liquid/Lotion Soap Dispenser | ||
 | H (Hand Wash) | Option: Hand Operation for Hand Wash Station | ||
 | KP1 | Option: Kick Plate for One-Station Basin | ||
 | LO | Option: Left Offset Toilet Configuration for Toilet-Lav Comby | ||
 | LWP | Option: Less Waste Piping | ||
 | OCC | Option: Corterra® Solid Surface | ||
 | PPZ | Option: Programmable Piezo Button | ||
 | RO | Right Offset Toilet Configuration for Toilet-Lav Comby | ||
 | SO | Option: (Hands-Free) Sensor Operation | ||
| SO-BAT | Option: (Hands-Free) Sensor Activated - Battery Powered | ||
 | ST | Option: Single Temperature |
Models
The model numbers are specified as shown below.
Model Number 3791-LO
Left Orientation
Shown with Sensor Operation,
Liquid/Lotion Soap Dispenser, and
OCC11M Blanco (Matte) Corterra
install guide
Model Number 3791-RO
Right Orientation
Shown with Sensor Operation,
Liquid/Lotion Soap Dispenser, and
OCC11M Blanco (Matte) Corterra
install guide
